Guillotine Paper Cutter
Itotec SC Series, Guillotine Paper Cutter – ITC02
$109,750.00
Itotec
SC Series
Itotec’s double-arm industrial paper cutters for commercial use are available in (4) size formats: 40″ (SC-100Z), 45″ (SC-115Z), & 54″ (SC-137Z), 63″ (SC-160Z)
In Stock Inventory
Watch Video- A safety beam guard is installed outside at both ends
- The touch panel is easy to observe and large
- The operation button is provided with a key top, improving the durability
- The knife speed and maximum backgauge advance speed are improved
- Front removal/installation of the false clamp has become possible
- The cover of the internal access window is changed to the gate type
- The maximum clamp pressure is increased
- Purchase Price Includes Installation, Training & Industry Leading 5-Year Warranty!
The accurate and long-life eRC Series paper cutting machine has further evolved, being released as SC Series.
More new functions have been added in pursuit of increased helpfulness and safety.
Ease of maintenance and efficiency are also enhanced. Install now and enjoy complete network connectivity that fulfils requirements of future needs. The technology and idea of ITOTEC which is well acquainted with the job site of paper cutting are packed in this new model.
The control panel located at the core of the SC Series paper cutting machine is programmed with functions needed to operate the paper cutting machine only. It starts immediately after power-on because of absence of unnecessary loads, so that work can be started immediately.
Itotec Cutters can now be equipped with the new Ultimate BestCut software. Using AI algorithms, BestCut simplifies the cut process by automatically planning the best cut sequence and advise the guillotine operator of the cut scenario to follow. Click here to learn more.
SC-100Z | SC-115Z | SC-137Z | SC-160Z | |
Cutting Width | 1030 mm | 40.55″ | 1168 mm | 45.98″ | 1370 mm | 53.94″ | 1600 mm | 62.99″ |
Cutting Depth | 1000 mm | 39.37″ | 1160 mm | 45.67″ | 1320 mm | 51.97″ | 1600 mm | 62.99″ |
Clamp Opening | 165 mm | 6.50″ | |||
Min. Cut Size | 27 mm | 1.06″ | |||
Knife Speed | 50 cycles/min. | |||
Max. Backgauge Speed | 300 mm/sec. | 11.81″/sec. | |||
Max. Clamp Pressure | 45 kN | |||
Display | 10″ TFT Color LCD Touch Panel | |||
Memory | 500 courses | 25,000 pages (50 pages/course) | |||
Knife & Clamp Driving Method | Double Pull Drive | |||
Machine Weight | 8,200 lbs. | 9,000 lbs. | 9,900 lbs. | 11,050 lbs. |
Machine Dimensions | 8.0′ L x 8.7′ W x 5.4′ H | 8.5′ L x 9.1′ W x 5.4′ H | 9.0′ L x 9.8′ W x 5.4′ H | 9.7′ L x 10.5′ W x 5.4′ H |
-
